8x4 4K HDR HDCP 2.2 Matrix Switcher with Digital Audio Routing

Print 8x4 4K HDR HDCP 2.2 Matrix Switcher with Digital Audio Routing pageRequest Bulk Pricing CAMCOR ITEM NO. 384055771 | MFG. PART NO. VS-84H2
8x4 4K HDR HDCP 2.2 Matrix Switcher with Digital Audio Routing
8x4 4K HDR HDCP 2.2 Matrix Switcher with Digital Audio Routing
Zoom
Close WindowZoom
Alternate View

MSRP: 4805.00
Savings: $961.00

Your Price: $3844.00
Quantity

Product Highlights
VS-84H2 is a high-performance 8x4 matrix switcher for 4K at 60Hz (4:4:4) HDR signals and digital audio routing. It reclocks and equalizes the signals and can route any one of 8 HDMI, HDCP-compliant ... More

Is This Item Right For Me? - Ask Our Experts
Phone 800.868.2462

WarningCalifornia Residents:
WARNING: Cancer and reproductive harm - See www.P65Warnings.ca.gov for more information.

Product Description

VS-84H2 is a high-performance 8x4 matrix switcher for 4K at 60Hz (4:4:4) HDR signals and digital audio routing. It reclocks and equalizes the signals and can route any one of 8 HDMI, HDCP-compliant sources (selectable) to any or all outputs simultaneously. VS-84H2 offers unmatched audio flexibility where any embedded digital audio input can be routed to any digital output in addition to four ARC sources to produce an equivalent 12x8 audio matrix.

  • High-Performance AV Matrix - Switches 8 4K at 60Hz (4:4:4), HDR, HDMI, HDCP (2.2/1.4)-compliant signals to 8 4K at 60Hz (4:4:4), HDR, HDMI, HDCP (2.2/1.4)-compliant outputs at up to 18G data rate. Featuring Kramer re-Klocking™ and Equalization Techn
  • HDMI Support - Deep Color, 3D, ARC, up to 7.1 uncompressed audio channels as specified in HDMI 2.0.
  • Independent Audio Routing - Any embedded digital audio input can be routed to any digital output, in addition to ARC sources, to produce an equivalent 12x8 audio matrix (8 embedded digital inputs + 4 ARC inputs and 4 digital outputs + 4 ARC outputs).
  • Easy Step-In Collaboration Function - When used with a Kramer Step-In enabled switcher, just plug in your device and press the Step-In button. Your device becomes the active signal on the main display.
  • EDID Management - Individual EDID management per input. Captures and stores the EDID from a display device.
  • Flexible Content Protection - Selectable HDCP per input.
  • Quick Access to Common Configurations - Save up to 16 preset configurations.
  • Smart Switching - Active source and acceptor detection. Automatic input selection based on priority selection or last connected input.
  • Embedded Pattern Generator - With selectable patterns.
  • Convenient Unit Control and Configuration Options - Local control via front panel switching, memory, lock and EDID buttons, and Input/Output LED display. Distance control via user-friendly embedded web pages via the Ethernet, Protocol 3000 API, and RS-23
  • Cost-Effective Maintenance - Input selection indicators facilitate easy local maintenance and troubleshooting. Firmware upgrade via Ethernet or mini USB.
  • Easy Installation - 19 inch enclosure for rack mounting in a 1U rack space with included rack ears and universal 100-240V AC power supply.
  • Included: Rack ears, rubber feet, power cord

Specifications

Specifications

Operating Temperature (Maximum)104.0000 F
Operating Temperature (Maximum)40 C
Operating Temperature (Minimum)0 C
Operating Temperature (Minimum)32.0000 F
AC Voltage (Maximum)240 Volts
AC Voltage (Minimum)100 Volts
Current Draw0.6 Amps

Product Dimensions

Depth7.2 in
Height1.72 in
Product Weight4.6 lbs
Shipping Depth (with packaging)12.99 in
Shipping Height (with packaging)4.21 in
Shipping Weight6.4 lbs
Shipping Width (with packaging)20.67 in
Width17.18 in
